850MHz 4G Navigation Car GPS Tracker Locator GSM GPRS Tracking Device For Motorcycle
Parameter
| Working Voltage: | DC9-100V or 12-40V, optional. |
| GSM Chip: | MT6261 |
| GPS Chip: | AT6558R |
| MPS | 9486 |
| Working temperature: | ‘-20 ℃ to +70 ℃ |
| Storage temperature: | ’-40 ℃ to +80 ℃ |
| Working Humidity: | 5% to 90% |
| Power consumption: | Average power consumption<1W, power-saving status<2mW |
| GPS Tracker size: | 76mm*27mm*15mm |
| Packing size: | 80mm*15mm*40mm |
| Interface: | Power input, ACC input detection, cut-off fuel circuit. |
| Communication band: | GSM/GPRS 850MHz 900MHz 1800MHz 1900MHz |
| Weight: | 50g
|
850MHz 4G Navigation Car GPS Tracker Locator GSM GPRS Tracking Device For Motorcycle
Main components: (V1.0)
COMPACT 4G GPS TRACKER - Perfect for tracking vehicles, loved ones (teens, spouses, children, elderly), or assets. With its sleek and compact design, it easily slips into cars, backpacks, strollers, luggage and is highly concealable. With 2G coverage slowly coming to an end, now is the time to upgrade to 4G.
REAL-TIME SMARTPHONE & PC TRACKING – With lighting fast 4G LTE this GPS tracker offers real-time tracking
- GEO-FENCING, SMART ALERTS & REPORTS - Create custom geo-fencing zones that alert you anytime the GPS tracker enters or exits a zone. Speed limit, harsh braking, start/stop and proximity alerts allow you to easily track your vehicles and loved ones. Receive text, push and email notifications directly to your smartphone or PC with the Amcrest GPS app and desktop web-access client. Access your data with intelligent reporting directly from your iPhone, Android, Mac, or PC
850MHz 4G Navigation Car GPS Tracker Locator GSM GPRS Tracking Device For Motorcycle
Device status indicators
4.1 Connect DC 9-100V power supply and the red LED will light continuously.
The red LED is the power signal,
it is always on when the external DC is connected.
4.2 The blue LED is the GSM signal indicator.
It is always on when there is no GSM;
it flashes when GSM is normal;
it flashes quickly when transmitting data.
4.3 The yellow LED is the GPS signal indicator:
it is always on when there is no positioning;
it flashes after positioning.
Terminal connection:
male switch, Female switch
Red(positive) Black (Negative)
1. red wire connect positive(+),black wire connect negative(-)
2. power input connector to power positive and negative connectors( make sure to connect the right connector)
3. When all indicators lighted and flashed normally means GPS Tracker works. now send SMS command to
communication network, you will receive a GPS Tracker status report by SMS.
GPS Tracker Main Functions:
1. Real-Time Positioning:
4G GPS Tracker Device will get the real-time position message and upload all status to the server system.
And will display the position on the map. you can click any of the points to know the name. locating time. and acc status. speed
GPS Time, direction, and so on.
2. Vibration alarm:
After setting the command of vibration by SMS. When it moves there will be a vibration alarm message.
3. Power-off alarm:
If the power supply of GPS Tracker is cut off or GPS Tracker will send the alarm message to the server or bonded Phone number.
4. Remote Car Lock
If an illegal ignition alarm receives from GPS Tracker, you can remotely cut off the vehicle circuit, so that to avoid being driven away.
5. SOS Alarm
Users can press the SOS button on GPS Tracker in emergency situations. GPS Tracker will send an alarm message to manage the system and
Call police simultaneously.
