Big Battery Pet GPS Locator Sleep Mode , Portable GPS Tracking
Performance Parameters:
| Content | Specs. |
| Dim | 105*60*20mm |
| Weight | 0.2kg |
| Network | GSM/GPRS |
| Band | 850/900/1800/1900MHz |
| GPS chip | Ublox-7 |
| GPS sensitivity | -159dBm |
| GPS accuracy | 5 m |
| Time To First Fix | Reacquisition 0.1s
Cold status 45s
Warm status 35s
Hot status 1s |
| Work Voltage | DC 3.7－4.5V |
| Battery | Chargeable changeable 3.7V / 5000Mah |
| Standby work current | < 30mA |
| Storage Temp. | -40°C to +85°C |
| Operation Temp. | -20°C to +70°C |
| Humidity | 5%--95% non-condensing |
Description:
1. Online web platform, the historical and current location can be checked.
2. Pet GPS Locator E-fence function.
3. Pet GPS Locator Hijack alarm, 9 SOS numbers can be preset.
4. Pet GPS Locator Remote voice monitoring.
5. Pet GPS LocatorLow battery alarm.
6. Admin checks the altitude and longitude and location information by texting.
7. A-GPS solutions,shorter locating time,higher precision.
8. Long Duration battery up to 48 hours fully working ( test under updating per 30 seconds).
9. Sleep model ,6000MAH battery, can work 10 days .
1. Google link: click link, there is map when positioning ok, no map means no positioning.
2. V:A GPS signal ok.V:V no GPS signal
3. 2013-08-30 20:54:15: the last time receive GPS signal.
4. Spd:000km/h: the speed of tracker ran. 5. Bat:6 battery balance(the range is from 1 to 9)
6. ID:4102000759: ID code of device(used for connect tracking website or APP)
7. S19G04；plmn:46001 GSM operator data 8.Lac:9516,cellid:23596 LBS data
7.1. Change password SMS format: pwd+old password,new password Example: pwd123456,666888 it will reply sms: “password OK” (Note:password should be 6 digits Arabic numbers)
7.2 Set admin phone number:
1). Add admin number: SMS format: adm123456,0086138******** Note1:The other admin numbers should be set by the first authorized number. If the number is su ccessfully authorized, the unit will reply “admin ok!” in SMS. Note2:Note:country code should be added in front of phone number)
2). Delete admin number: SMS format: adm123456, Example: adm123456, Reply sms: ADM!A1:
7.3. Track on demand:
1). GPS without admin numbers: Any cellphone dial up the GPS simcard,tracker device will reply by sms locations information ,as below:
2). Track by GSM Location(Only for admin phone,default:closed)
Command to open :addjz=1 Command to close :addjz=0
Detail Pictures:
Applications:
1. Vehicle rental / Fleet management etc
2. Outdoor sports
3. Protect children / elder/ Asset/ pet and so on
4. Provide peace‐of‐mind for businessmen
5. Personnel Management
6. Criminals Tracking
Pet shop, pet company, ,GPS producer, large-scale shopping malls, exclusive agency, chain shops, large-scale sales,
Gurantee:
1. All of our product is free to use the Tracking service server in 24 hours each day
2. All of our product there is a 2 year quanlity assurance.
3. Sample fee will not be returned.
Product Configuration:
1. Standard configuration
1) main device 1 pcs
2) charger 1 pcs
3) Installation cables 1 set
4) Usage instructions
5) Warranty card
6) Certification
